| 픽셀 피치: | 10mm | 명도: | 6500cd/sqm |
|---|---|---|---|
| LED 칩: | SMD 3535 | 모듈 크기: | 320*160mm |
| 보기 거리: | 10m --- 70m | 수명: | 100000 시간 |
| 운전 방법: | 1/4 상수 전류를 스캔합니다 | 물리 밀도: | 100000dots/제곱 미터 |
| 픽셀 구성: | 1R1G1B | 모듈 해상도: | 32*16 |
| 모듈 전원: | 70W | 보기 각도: | H: 120°; V:120° |
| 최대 전력 소비: | 620W | Avg 소비 전력: | 250W |
| 캐비닛 크기: | W960mm × H960mm | ||
| 강조하다: | P10 outdoor LED display 10mm pixel,LED video display 6500cd brightness,outdoor advertising LED screen with warranty |
||
| Attribute | Value |
|---|---|
| Usage | Outdoor |
| Tube Chip Color | FULL COLOR |
| Display Function | Video |
| Pixels | 10mm |
| Brightness | 6500cd/sqm |
| LED chip | SMD 3535 |
| Module size | 320*160mm |
| Certificate | CE RoHS FCC Certifications |
| Recommended viewing distance | 10m---70m |
| Life span | 100000hours |
| Warranty | 2 years |
| Driving method | 1/4 Scan Constant Current |
| Screen Dimension | Customized Size |
LED technology has revolutionized visual displays worldwide. As a premier application of this technology, LED screens are now universally used across various industries, delivering exceptional visual experiences that enhance our environment.
SHENZHEN KAILITE OPTOELECTRONIC CO.,LTD is a professional LED display manufacturer offering complete, customized LED screen solutions at competitive prices with guaranteed quality.
| Item | PH10 |
|---|---|
| Module size | 320*160mm |
| Physical density | 10000dots/square meter |
| Pixel configuration | 1R1G1B |
| LED chip | SMD3535 |
| Module resolution | 32*16 |
| Module power | 70w |
| Best viewing angle | H: 120°; V:120° |
| Maximum power consumption | 620w |
| Average power consumption | 250w |
| Cabinet size | W960mM×H960mm |
| Standard cabinet resolution | 96*96 |
| Weight | 35kg/panel |
| Frame frequency | ≥60 Hz |
| Refresh frequency | ≥1200Hz |
| Operating temperature/Humidity | -30℃~+45℃ 10%~95% |
| Ingress protection | Front:IP 67; Back:IP65 |
| Input voltage | 110-220V AC±10% |
| Gray scale /Color | Display Colors ≥16.7N(Synchronize) |
| Input signal | RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc |
| Control system | PCTV+DVI video card+control card+fiber |
| Life time | >100,000 Hours |
1. What other models do you offer?
We provide a complete range of LED displays including indoor models (P2.5, P3, P3.91, P4, P4.81, P5, P6, P7.62, P10) and outdoor models (P5, P6, P8, P10).
2. What is your warranty policy?
We offer a 2-year warranty with lifetime maintenance support.
3. What content can your LED screens display?
Our displays support videos, flash animations, WAV/MIDI audio, PowerPoint presentations, images, and more.
4. What is your typical delivery time?
Delivery typically takes 15-25 days after receiving deposit.
5. How do you package and ship your products?
Products are securely packed in wooden or flight cases and shipped via air or sea freight.
We are confident our service and quality will exceed your expectations!
