| 픽셀 피치: | 10mm | 모듈 크기: | 320*160mm |
|---|---|---|---|
| 물리 밀도: | 100000dots/제곱 미터 | 픽셀 구성: | 1R1G1B |
| LED 칩: | SMD3535 | 모듈 해상도: | 32*16 |
| 모듈 전원: | 45W | 추천하는 시선거리: | 10-70M |
| 보기 각도: | H: 120°; V:120° | 최대 전력 소비: | 850W |
| 평균 전력 소비: | 420W | 캐비닛 크기: | W960m × H960mm |
| 표준 캐비닛 해상도: | 96*96 | 무게: | 38kg/패널 |
| 운전 방법: | 1/4 스캔, 일정한 전류 | ||
| 강조하다: | P10 outdoor LED display screen,10mm pixel pitch LED screen,full color outdoor LED display |
||
| Attribute | Value |
|---|---|
| Display Function | Video |
| Screen Dimension | Customized |
| Tube Chip Color | FULL COLOR |
| Use | Outdoor |
| Pixels | 10mm |
| Application | Live Events Led Display, Advertising, Movies |
| Certificate | CE RoHS FCC Certifications |
| Brightness | 10000cd/sqm |
| Color | 1R1G1B |
| Led chip | SMD3535 |
| Module size | 320*160mm |
| Warranty | 2 Years |
| Product name | P10 outdoor display |
| Viewing Angle | H120 V120 |
| Pixel pitch | 10mm |
LED technology has revolutionized visual displays worldwide. As a premier application of this technology, LED screens are now universally used across various industries, delivering stunning visual and auditory experiences that make our world more vibrant and beautiful.
SHENZHEN KAILITE OPTOELECTRONIC CO.,LTD is a professional LED display manufacturer offering complete and personalized LED screen solutions at competitive prices with guaranteed quality.
| Item | PH10 |
|---|---|
| Color | Full-color real pixels |
| Use environment | Outdoor |
| Pixel pitch | 10mm |
| Module size | 320*160mm |
| Physical density | 10000dots/square meter |
| Pixel configuration | 1R1G1B |
| LED chip | SMD3535 |
| Module resolution | 32*16 |
| Module power | 45w |
| Recommended viewing distance | 10-70m |
| Best viewing angle | H: 120°; V:120° |
| Maximum power consumption | 850w |
| Average power consumption | 420w |
| Cabinet size | W960m×H960mm |
| Standard cabinet resolution | 96*96 |
| Weight | 38kg/panel |
| Driving method | 1/4 Scan, Constant Current |
| Video frame rate | ≥60 Hz |
| Rate refresh | ≥1200Hz |
| White balance brightness | ≥5500cd |
| Operating temperature/Humidity | -30℃~+45℃ |
| Ingress protection | Front:IP 43 |
| Input voltage | 110-220V AC±10% |
| Gray scale /Color | Display Colors ≥16.7N(Synchronize) |
| Brightness control | Manual/Automatic |
| Input signal | RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc |
| Control system | PCTV+DVI video card+control card+fiber |
| MBTF | >5000 hours |
| Life time | >100,000 Hours |
| The rate | <0.0001 |
Yes, we offer a complete range of LED screens including indoor models (P2.5, P3, P3.91, P4, P4.81, P5, P6, P7.62, P10) and outdoor models (P5, P6, P8, P10).
Yes, we are an 8-year established factory offering 2 years warranty with lifetime maintenance support.
Our displays support videos, flash animations, WAV/MIDI audio, PowerPoint presentations, images, and more.
Delivery typically occurs within 15-25 days after receiving deposit.
Products are securely packed in wooden cases or flight cases, shipped via air or sea freight according to customer requirements.
Shenzhen KAILITE Optoelectronic Co., Ltd. is a professional LED screen manufacturer with years of experience and numerous successful international projects. We provide complete solutions tailored to your specific requirements.
Our competitive advantages include scale production benefits, direct factory pricing, and a commitment to quality and service that ensures customer satisfaction. We value long-term business relationships built on loyalty, credibility, and integrity.
